Common fault |
Main reasons |
Eliminating methods |
Push a button motor don't turn |
1,Connection broken or loose |
1,Repair wiring |
2,Switch |
2,Repair or replace the switch |
3,Capacitors to burn out |
3,Replace capacitance |
4,Limit is not reset or travel switch |
4,Repair limit or travel switch |
1,Electrical brake failure |
1,Adjust brake piece clearance or replacement |
Electrical brake failure |
2,Brake spring fracture |
2,Replace brake spring |
3,Braking has serious pollution |
3,Clean brake piece |
Electrical noise hanging motionless weight
|
1,Low voltage |
1,Stay voltage is normal |
2,Capacitor damage |
2,Replace capacitance |
3,Brake piece not completely |
3,Adjust brake piece clearance |
Pedal brake force is too small |
1,Pins slippage |
1,To properly |
2,Braking with fracture |
2,Replace brake just take |
3,With the loss of braking |
3,Socket pin exchange |
Machine noise |
1,Bad lubrication |
1,Add the lubricating oil |
2,Gears, bearings damage |
2,Check gear replacement or bearing |
3,Not to install the revolver, touch shell |
3,Reinstall it |
